SEALANTS, LUBRICANTS

AND ANTI-SEIZES

Topco’s thread compounds have been formulated for over 50 years. They are constantly being upgraded and improved to handle the ever-changing drilling and production environments. Our thermal compound is globally recognized for its application on conventional and premium tubulars used in steam and SAG-D projects. Topco also has a full line of environmental products for both drilling connections and production tubulars and small container industrial products.

Many of our Compounds comply with the physical, chemical and performance requirements as specified by API 7A1 and 5A3.

Production

API Modified
API Modified contains heavy metals that prevent thread galling on new as well as reconditioned tubulars. The plating of the metals in the thread root and crown provides maximum thread protection against over torquing and minimizes connection damage during breakout procedures. The coefficient of friction (COF) for API Modified is 1.0. This product complies with all the specifications of API Technical Bulletin 5A2.

A yellow and black cylinder with a metal spring.Service Recommendations:
API casing, tubing, and line pipe connections.

Packaging:
10L metal/2.5 gal | Net 15.9kg/35lb
20L metal/5 gal | Net 22.7kg/50lb
205l metal/55 gal drum| Net 294.8kg/650lb

Product Specifications:
Service Rating: 200°C/392°F
Drop Point: 200°C/392°F
Brushability: -40°C/-40°F
Torque Correction Factor: 1.0

SDS English | SDS French | SDS Spanish

Product Data Sheet

API Modified Silicone
Additional information provided upon request

SDS English

Green-Seal® Supreme
Green-Seal® Supreme is a premium grade thread compound that is formulated as a sealant and a lubricant for tubing and casing. This compound was formulated to provide a TCF of 1.0 that would be equivalent to that of API 5A2. Green-Seal® Supreme contains chemical inhibitors to resist the attack of H2S as well as providing protection against pitting corrosion. It exceeds the technical specifications of API bulletins 5A2 and 5A3.

A can of green seal supremeService Recommendations

Green-Seal® Supreme is recommended for use on all API casing, tubing and premium threaded connections.

Packaging:
10L metal/2.5 gal | Net 13.6kg/30lb
20L metal/5 gal | Net 22.7kg/50lb
170L metal/55 gal | Net 22.7kg/50lb

Product Specifications:
Service Rating: 200°C/392°F
Drop Point: 240°C/464°F
Brushability: -18°C/0°F

SDS English

Product Data Sheet

NLC-Modified
NLC-Modified was developed to comply with an industry requirement to eliminate lead based products used for production tubing and well casing. Increased environmental regulations called for the reduction of heavy metals on well sites.

NLC-Modified was formulated as a non-lead compound. It contains powdered zinc and copper fines that control torque during make-up, provide a seal in the helix during production cycles, and ensure that break-out of connections will be clean and without galling.

This product has been blended as a standard compound and well as under private brand labelling for the larger E&P companies.

A yellow and black cylinder with a metal spring.Service Recommendations

NLC-Modified may be used on all API tubing, casing and line pipe.

Packaging:
10L metal/2.64 gal | Net 15.9kg/35lb

Product Specifications:
Service Rating: 200°C/392°F
Drop Point: 240°C/464°F
Brushability: -18°C/0°F

SDS English

Product Data Sheet

Green-Seal® II
Green-Seal® II is a premium grade non-metallic thread compound that is formulated as a sealant and a lubricant for tubing and casing. This compound was originally developed to comply with the
requirements of the California Code on the regulation of toxic substances. Green-Seal® II contains chemical inhibitors to resist the attack of H2S aswell as providing protection against pitting
corrosion. It exceeds the technical specifications of API bulletins 5A2 and 5A3.

A green bucket of paint on top of a table.Service Recommendations:
Green-Seal® II is recommended for use on all API casing, tubing and premium threaded connections.

Packaging:
10L metal/2.5 gal | Net 13.6kg/30lb
12L plastic/3 gal | Net 22.7kg/50lb
20L metal/5 gal | Net 22.7kg/50lb
205L metal/55 gal drum | Net 227kg/500lb

Product Specifications:
Service Rating: 200°C/392°F
Drop Point: > 204°C/400°F
Brushability: -40°C/-40°F
Torque Correction Factor: 0.90

SDS English | SDS French | SDS Spanish

Product Data Sheet

Eco-Seal
Eco-Seal is an economical non-metallic compound formulated for use as a lubricant and sealant. It does not contain any restricted substances as defined by the California Code of Regulations on toxins and hazardous materials.

A yellow and black cylinder with a metal spring.Service Recommendations:

Service Recommendations:
Tubing, casing, and line pipe connections.

Packaging:
10L metal/2.5 gal | Net 9.1kg/20lb
20L metal/2.5 gal | Net 22.7kg/50lb

Product Specifications:
Service Rating: 150°C/302°F
Drop Point: 240°C/464°F
Brushability: -18°C/0°F

SDS (English) – USA | SDS (English) – CAN | SDS (French) – CAN

Product Data Sheet

Green- Seal® II Thermal
Green-Seal® II Thermal is a premium grade non-metallic thread compound that is formulated as a sealant and a lubricant for tubing and casing. This compound was originally developed to comply with the requirements of the California Code on the regulation of toxic substances. Green-Seal® II Thermal contains chemical inhibitors to resist the attack of H2S as well as providing protection against pitting
corrosion. It exceeds the technical specifications of API bulletins 5A2 and 5A3.

A yellow and black cylinder with a metal spring.Service Recommendations:

Green-Seal® II Thermal is recommended for use on all API casing, tubing and premium threaded connections in extreme temperature conditions.

Packaging:
10L metal/2.5 gal | Net 13.6kg/30lb
20L metal/5 gal | Net 22.7kg/50lb

Product Specifications:
Service Rating: 371°C/700°F
Drop Point: 386°C/727°F
Brushability: -18°C/0°F

SDS English | SDS Japanese

Product Data Sheet

TK II Modified
TK II Modified® is a synthetic based thermal compound developed for use in geo-thermal, steam injection and SAG-D projects. This product provides a leak-proof seal in both API and premium connections where elevated temperatures and higher pressures are determining factors. The finely powdered metals prevent over torque, galling, and seizure during connection make-up and break-out. Chemical inhibitors minimize the effects of corrosive environments.

Service Recommendations:

TK II Modified® is recommended for all API and premium heavy wedge style threads connections in high temperature conditions.

Packaging:
10L metal/2.5 gal | Net 30lb
20L metal | Net 50lb
170L metal | Net 480 lbs

Product Specifications:
Service Rating: 345°C/650°F
Drop Point: 400°C/752°F
Brushability: -18°C/0°F

SDS English | SDS French

Product Data Sheet

Thermal-Seal
Thermal-Seal was developed as an economical high temperature compound for standard tubulars used in production of thermally cycled wells. It was formulated for heavy oil sand operations where steam cycling and soak operations require a product that seals during excess temperatures and pressures.

Thermal-Seal has a partial synthetic based carrier that provides compound stability during formation heating.

This formulation contains metals as well as additives to prevent metal compaction in the thread crests and roots during make-up and break-out of tubulars.

Service Recommendations

Thermal-Seal is to be used on conventional API tubing in high temperature production environments.

SDS English

Thermal-Kote

Drilling

NL Collar
NL Collar is a non-lead compound developed as a replacement product for the traditional lead-based sealants used to cushion drill collar threads. This thread compound protects the larger diameter threads from galling and seizing during make-up and break-out in the most demanding of drilling conditions. NL Collar contains extreme pressure additives as well as corrosion inhibitors to maximize connection life.

A yellow and black cylinder with a metal spring.Service Recommendations

Recommended for all tool joints and drill collar threads in medium to heavy duty drilling conditions.

Packaging:
10L metal/2.64 gal | Net 15.9kg/35lb

Product Specifications:
Service Rating: 200°C/392°F
Drop Point: 240°C/464°F
Brushability: -18°C/0°F

SDS English

Product Data Sheet

JWW®
JWW® is a premium quality rotary joint compound blended for use on drill collars and tool joints. The formulation contains additives for extreme pressure control in high torque deep hole drilling conditions. Corrosion inhibitors ensure maximum resistance to pitting and rusting of tubulars while being racked and stored.

A yellow and black cylinder with a metal spring.Service Recommendations:
JWW® is recommended for all rotary joint connections in moderate to severe drilling
conditions.

Packaging:
17L metal/4 gal | Net 15.9kg/35lb

Product Specifications:
Service Rating: 200°C/392°F
Drop Point: > 160°C/320°F
Brushability: -40°C/-40°F
Torque Correction Factor: 1.10

SDS English | SDS French

Product Data Sheet

Zincote®
Zincote® is an API formulated thread compound that has been the industry standard for all rotary shouldered connections since the early 1950s. This compound contains a 50% loading of finely powdered zinc and is used on both tool joints and drill collars.
Zincote® has a premium base grease carrier and has both a high temperature service rating as well as providing maximum adhesion of the compound to cold, damp threads.
Zincote® contains corrosion inhibitors to prevent rusting of connections when tubulars are placed in storage conditions.

A yellow and black cylinder with a metal spring.Service Recommendations
Zincote® is the recommended compound for any rotary joint tubular including both drill collars and tool joints.

SDS English

Product Data Sheet

65% Zincote®
65% Zincote® is an API formulated thread compound that has been the industry standard for all rotary shouldered connections since the early 1950s. This compound contains a 65% loading of finely powdered zinc and is used on both tool joints and drill collars.
65% Zincote® has a premium base grease carrier and has both a high temperature service rating as well as providing maximum adhesion of the compound to cold, damp threads.
65% Zincote® contains corrosion inhibitors to prevent rusting of connections when tubulars are placed in storage conditions.

A yellow and black cylinder with a metal spring.Service Recommendations
65% Zincote® is the recommended compound for any rotary joint tubular including both drill collars and tool joints. The high volume of metal is most useful in applications involving invert chemistry where fluids leech out the grease carrier and lead to wash out of the solids in the connections and leaking of the joint.

Product Data Sheet

All-Star
All-Star is a premium quality rotary joint thread compound that is blended for drill collars in extreme pressure and high torque conditions. The formula contains 60% of finely powdered metallic lead that is used to absorb shock as well as seal the connection under pressure.

All-Star is manufactured according to the specifications of API.

Non-metallic particles are used in the formulation to prevent metal compaction in the shoulder and thread roots. This ensures a clean breakout during tripping cycles.

A yellow and black cylinder with a metal spring.Service Recommendations

All rotary shouldered connections used in high torque and deep or long horizontal drilling operations.

Packaging:
10L metal/2.5 gal | Net 20.4kg/45lb

Product Specifications:
Service Rating: 200°C/392°F
Drop Point: 240°C/464°F
Brushability: -18°C/0°F
Torque Correction Factor: 1.11

SDS English | SDS French

Product Data Sheet

Cop-R-Lube®
Cop-R-Lube® is a versatile thread compound blended for use on rotary shouldered connections. It has extreme pressure additives as well as corrosion inhibitors to ensure that threads are protected during make-up and breakout and has resistance to rusting and galvanic pitting.
Cop-R-Lube® is also recommended for the break in of new tool joints and drill collars. During this initial cycle the fine metallic copper plates on the thread surfaces and acts as an anti-seize when the tubulars are being run in a drilling operation. This thread compound is available in both standard and high temperature formulas.
Cop-R-Lube® is the anti-seize suggested for use on any threaded metal parts or fittings prior to assembly or thread engagement. It protects against corrosion, eases disassembly, and minimizes equipment downtime during repair and maintenance.

A yellow and black cylinder with a metal spring.Service Recommendations
Any rotary shouldered connections including tool joints and drill collars. It is also the product suggested for small service industries such as automotive and appliance repair business.

Packaging:
10L metal/2.5 gal | Net 13.6kg/30lb
20L metal/5 gal | Net 22.7kg/50lb

Product Specifications:
Service Rating: 200°C/392°F
Drop Point: 240°C/464°F
Brushability: -40°C/-40°F
Torque Correction Factor: 1.15

SDS (English) – CAN | SDS (French) – CAN

SDS (English) – EU/UN GHS | SDS (French) – EU/UN

Product Data Sheet

RJC®
RJC® has been formulated as an environmentally acceptable product used by drilling operators on rotary joint tubulars such as tool joints and drill collars. The compound has been used in both Canada as well as the USA in difficult drilling conditions and at depths exceeding 7,500 m or 25,000 feet.

RJC® has extreme pressure additives that cushion the threads against galling and sharpening during breakout. Corrosion inhibitors provide protection from the harsh chemicals used in the drilling fluids and muds as well as preventing pitting caused by exposure to H2S.

A yellow and black cylinder with a metal spring.Service recommendations
All rotary joint connections.

Packaging:
16L plastic/4.2 gal | Net 15.9kg/35lb

Product Specifications:
Service Rating: 240°C/464°F
Drop Point: 260°C/500°F
Brushability: -18°C/0°F
Specific Gravity: 1.04g/cc

SDS EnglishSDS FrenchSDS Spanish

Product Data Sheet

High Temp Cop-R-Lube

Additional information provided upon request

SDS English

DSV-12 has been formulated as a running compound for double shouldered connections in severe drilling service. This premium grade, high temperature compound has been tested on double shouldered wedge thread TM connections in high torque conditions.

Topco’s standard calcium complex base grease is used as the base in blending this non-metallic product that also contains anti-wear and extreme pressure additives. The calcium complex sulfonate provides superior adhesion of the finished compound to wet steel tubulars in cold as well as hot temperature environments. Sulfonate chemistry is proven as an effective means to prevent water wash-off and provide corrosion resistance.

A yellow and black cylinder with a metal spring.Service Recommendations:
Double shouldered rotary joint connections, such as tool joints and drill collars, at higher torques in severe drilling conditions; Invert systems & MWD Applications.

Packaging:
20 L/5 US Gal Steel | Net 15.9kg/35lb

Product Specifications:
Service Rating: 240°C/464°F
Drop Point: > 204°C/400°F
Brushability: -40°C/-40°F
Friction Factor: 1.15
NLGI Grade: 1

SDS English

Product Data Sheet

Specialty

BioBlend

A yellow and black cylinder with a metal spring.

These products are specifically designed for plunger packing lubrication of triplex and quintuplex pumps.

Topco also carries & distributes all other Bioblend products! www.BioBlend.com

BioBlend PPL Data Sheet w/ Arctic | BioGrease_PPG Data Sheet

Kendex G043 OCTG

Additional information provided upon request.

Product Data Sheet

SDS English | SDS French

UPT-M

Additional information provided upon request

SDS English | SDS French | SDS Portuguese EU CLP Only | SDS Portuguese | SDS Spanish EU CLP Only | SDS Spanish

SRL

A yellow and black cylinder with a metal spring.

Topco’s SRL was formulated as a specialty lubricant to provide for the consistent control of torque during the make-up of sucker rod threads. For many years there was not a recommended product for sucker rod threads and field operations used diesel, API Modified compound or ran dry during installation of the sucker rods in a well.
SRL has a heavy loading of corrosion inhibitors to prevent thread pitting damage caused by well fluids, H2S, or having rods being stored in an outdoors environment.

SRL was developed for field operations and is packaged in polyethylene squeeze top bottles for convenience of application and to avoid wasting of the product. This lubricant is also used by a number of manufacturers as their standard inhibitor for storage and transport of sucker rods to the field.

Service Recommendations
Blended for use as a lubricant ONLY for sucker rods threads

Packaging:
1L plastic | Net .9kg/2lb

SDS English | SDS French | SDS Spanish    Product Data Sheet



Industrial

Cop-R-Lube

Cop-R-Lube® is a versatile thread compound blended for use on rotary shouldered connections. It has extreme pressure additives as well as corrosion inhibitors to ensure that threads are protected during make-up and breakout and has resistance to rusting and galvanic pitting.
Cop-R-Lube® is also recommended for the break in of new tool joints and drill collars. During this initial cycle the fine metallic copper plates on the thread surfaces and acts as an anti-seize when the tubulars are being run in a drilling operation. This thread compound is available in both standard and high temperature formulas.
Cop-R-Lube® is the anti-seize suggested for use on any threaded metal parts or fittings prior to assembly or thread engagement. It protects against corrosion, eases disassembly, and minimizes equipment downtime during repair and maintenance.

A yellow and black cylinder with a metal spring.Service Recommendations
Any rotary shouldered connections including tool joints and drill collars. It is also the product suggested for small service industries such as automotive and appliance repair business.

Packaging:
10L metal/2.5 gal | Net 13.6kg/30lb
20L metal/5 gal | Net 22.7kg/50lb

Product Specifications:
Service Rating: 200°C/392°F
Drop Point: 240°C/464°F
Brushability: -40°C/-40°F
Torque Correction Factor: 1.15

SDS English | SDS French

Product Data Sheet

Pure Nickel

Pure Nickel is a premium grade anti-seize compound blended for use in applications where a copper based product is prohibited such as for fittings in chemical plants. Pure Nickel is also used on stainless steel products in the petroleum industry such as downhole production pumps and fluid ends used on high pressure pumps by the fracking and cementing contractors.

Pure Nickel contains a high loading of finely powdered nickel suspended in a calcium complex grease carrier. It provides protection against metal degradation in highly corrosive and extreme temperature services.

A yellow and black cylinder with a metal spring.Service Recommendations
Any threaded fitting, bolts, or studs and nuts in extreme service conditions. Pure Nickel is the recommended thread compound for all stainless steel connections.

SDS English

Product Data Sheet

Tuf-Lon

Additional information provided upon requestA yellow and black cylinder with a metal spring.

SDS English

Frequently Asked Questions

THREAD COMPOUND APPLICATION / DOPING PROCEDURE
  • Threads must be clean and free of contaminants such as dirt, metal filings etc.
  • Connections may be cleaned using a soft brush or clean cloths. Solvents, such as diesel, varsol should not be used unless the connection is thoroughly dried afterwards. Connections that have residual solvents on the threads will have improper makeup torques as the solvent base affects the friction factors.
  • If fluid is present in the box it should be removed before applying thread lube.
  • Never use two different compounds on the same connection as the makeup torque will be affected.
  • Clean compound should be applied using a dope brush that does not have contaminants on it. This includes dirt and grit, another type of compound, or a residual solvent.
  • Compound is applied on the threads in a circular motion to ensure that the entire thread profile and the Seal SURFACE has compound coverage.
  • The application of compound to one or both sides of a joint is subject to the pipe manufacturer’s specifications. The process of makeup of the joint does not guarantee that the compound will be equally spread over the surface of the threads as the pin engages the box.
  • Pipe pin ends must be lubricated evenly prior to make up particularly on double shouldered pipe.
  • Proper coverage of the threads with a clean compound provides consistent makeup torque, ensures a good seal in the connection, and minimizes the chances of thread damage from galling.
WHAT IS THE SHELF-LIFE OF A TOPCO THREAD COMPOUND?

Compounds have a shelf life of two years. All batch numbers are traceable to manufacturing dates. Product that has passed an expiry date should be returned for a re-blend.

DO THREADS NEED TO BE CLEANED BEFORE COMPOUND APPLICATION?
Connection threads should be cleaned to remove any contaminants such as metal filings, dirt, or an incompatible thread compound. A soft brush is recommended.
CAN VARSOL OR ANOTHER SOLVENT BE USED TO CLEAN OFF THE THREADS?
Yes such solvents may be used. The connection must be thoroughly dried afterwards with a clean cloth to remove any residual film.
WHAT IS AN ENVIRONMENTAL COMPOUND?
An environmental compound is one that is in compliance with the local and national jurisdiction, or meets a customer’s specific requirements.
IS IT POSSIBLE TO USE A CASING COMPOUND ON A ROTARY SHOULDERED CONNECTION OR VICE VERSA?
NO, tubing and casing compounds may NOT be used on a rotary joint connection. The wrong type of compound may cause downhole makeup leading to high thread stress and galling during break-out.
DOES THE RATE OF CONNECTION MAKEUP SPEED AFFECT THE PERFORMANCE OF THE COMPOUND?
Yes, a slow to moderate makeup speed allows the solids to spread evenly into the connection giving a better seal. Too high of a tong make-up speed creates connection stress, does not permit even distribution of the solids, and leads to a poorer seal.
